10.24kWh LiFePO4 SOLAR BATTERY LFRX 51.2V 200Ah 6000 Cycles
- Code:LFR51200
- Weight:75.000 Kgs
- Brand:LVFU
Quick Buy
Just 2 fields to fill in
10.24kWh LiFePO4 SOLAR BATTERY LVFU 51.2V 200Ah 6000 Cycles
General Information:
LVFU battery is made of Grade-A cells, lithium iron phosphate materials, built-in BMS, up to 16 units in parallel, with multiple certificates (UN38.3, CE, MSDS, etc.)
Features:
- Voltage Options: Available in 48V DC and 51.2V DC standard voltage.
- Energy Efficiency: Boasting an impressive 98% efficiency at 0.5C, our LiFePO4 battery ensures optimal energy utilization.
- Communication Protocols: Versatile connectivity options include CAN, RS485, RS232, WIFI, 4G, and Bluetooth for advanced monitoring and control.
- Long Cycle Life: With a cycle life of 6000 cycles at 80% Depth of Discharge (DoD), our battery guarantees a reliable and extended lifespan.
- Robust Protection: Equipped with comprehensive protection mechanisms, including over-temperature, over-current, short circuit, over-charging, over-discharging, and low voltage safeguards.
- Charge and Discharge Specifications: Tailor your energy usage with recommended and maximum charge/discharge currents and voltages.
- Mechanical Excellence: Industrial-grade iron construction ensures durability, and the rack-mounted design allows for easy installation in a cabinet.
Certifications and Compliance:
- Certified with CE, FCC, and CCC standards, ensuring quality and safety.
- Compliant with UN 38.3, UN 3480, Class 9 for safe shipping.
Temperature Specifications:
- Wide operating temperature range from -20°C to 65°C for reliable performance in various environments.
Upgrade to our 48-volt LiFePO4 battery and experience a reliable and efficient power solution. Choose the perfect combination of voltage and capacity to suit your specific requirements. Invest in a power source that delivers performance, longevity, and peace of mind.
Rack-mounted energy storage (Home/Industrial)
Model LFR-4850/5150
- Standard Voltage: 48VDc/51.2VDc
- Voltage: 39.75-54.75VDc/42.4-58.4VDc
- Nominal Capacity: 200Ah
- Rated Energy Capacity: 10.24kWh
- Communication Protocol: CAN/RS485/RS232/WIFI/4G/Bluetooth
- Efficiency (at 0.5C): 98%
- Cell Self-Discharge: <5%/Month
- Maximum Allowed Modules in Parallel: 15 (36/38.4kWh)
- Depth of Discharge: Up to 100%
- Useful Life: 8-10 Years
- Cycle Life: 6000 (@ 80% DoD)
- Protection: Over temperature, over current, short circuit, over-charging, over-discharging, low voltage
- Charge Specifications:
- Recommended Charge Current: 50A
- Maximum Charge Current: 100A
- Recommended Charge Voltage: 54/57.6V
- Maximum Charge Voltage: 54.75/58.4V
- Discharge Specifications:
- Recommended Discharge Current: 50A
- Maximum Discharge Current: 100A
- Recommended Low Voltage Disconnect: 41.25/44V
- Battery Low Voltage Protection: 39.75/42.4V
- Battery Recovery Voltage: 45/48V
- Mechanical Specifications:
- Dimensions: 560*410*200mm
- Weight: 75kg
- Terminal Type: M6
- Case Material: Industrial Grade Iron
- Enclosure Protection: IP20
- Installation: Cabinet
- Cell Type Chemistry: LiFePO4
- Compliance Specifications:
- Certifications: CE, FCC, CCC
- Shipping Classification: UN 38.3. UN 3480, Class 9
- Temperature Specifications:
- Discharge Temperature: -20~65°C
- Charge Temperature: 0~55°C
- Storage Temperature: -20~45°C
- Warranty:5 years
- IP Rating:20
- Weight:75 kg.
| File | Info |
|---|---|
 LFR51100-Operation Manual for LFR Series Rack-Mounted Battery | [PDF, 1.05 MB] |
| LFR51100 -Inverter-Compatibilty | [PDF, 140.83 KB] |
| LFR51100-MSDS | [PDF, 492.61 KB] |
| LFR51100 -CE | [PDF, 673.11 KB] |
| IEC--LFR51100 | [PDF, 608.21 KB] |
