LITHTECH 25.6V 100Ah LiFePO4 Battery Pack

• Compact Design: Module automotive grade anti-vibration design.
• Support Connecting in Parallel & Series: Flexible connection options for customized applications.
• Independent Bluetooth APP: Supports both Android & iOS systems.
• High & Low Temperature Protection: Supports low-temperature charging and provides overcharge, discharge, over-voltage, and short circuit protection.
• Long Cycle Life: Over 5000 cycles
• Optional Communication: CAN/RS485/RS232 communication supported.

Specifications

Electrical Characteristics
Nominal Voltage	25.6Volt
Nominal Capacity	100Ah
Energy	2560Wh
Internal Resistance	≤45mΩ
Cycle Life	5000 Cycles
Months Self Discharge	≤3.5% per month at 25℃
Standard Charge
Charge Voltage	28.4V~29.2V±0.2V
Charge Current	50A
Max. Charge Current	100A
Standard Discharge
Discharge Current	80A
Max. Continuous Current	100A
Peak Current	260A (<3S)
Discharge Cut-off Voltage	17.6V
Environmental
Charge Temperature	0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature	-20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature	0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity
Water & Dust Resistance	IP67
Mechanical
Cell & Method	LFP/AL-100AH, 4S1P Plastic
Plastic Case	ABS
Dimension (L*W*H)	487*170*240mm
Weight	22kg
Terminal	M8
