20kW Solar System with 32kWh Battery Storage and Hybrid Inverters

Complete package for a 20kW single-phase hybrid solar system, including 2 × 10kW CHISAGE Jup-10G2-LE low-voltage hybrid inverters with WiFi and a 12-year warranty, together with 2 × 16.08kWh CHISAGE MOON16-GPro LiFePO4 batteries providing a total storage capacity of 32.16kWh.

The photovoltaic section consists of 36 × 605W bifacial N-Type JA Solar panels measuring 2278 × 1134 × 30 mm. The total peak PV capacity is 21.78kWp. The batteries use EVE cells and CN BMS technology and are designed for up to 6000 cycles.

The package includes aluminium mounting rails and clamps for sandwich panels, MC4 connectors, 6mm² solar cables, DC protection boxes with surge protection, a single-phase AC distribution box with ATS, protection devices, fuses and contactor, as well as grounding components. The system generates electricity from sunlight, while surplus energy can be stored in the batteries and used later. This increases self-consumption, reduces dependence on the electrical grid and provides a reserve of stored energy.

Installation of the equipment is not included in the package.
